    Product description

    The UT661 series pipeline blockage detectors can quickly locate blockages clogging inside pipelines. They are able to detect pipes from a maximum distance of 50cm, the signal wire can be inserted into pipelines up to 35m for UT661D respectively. UT661 series are easily operable, and can be used to detect steel, iron, and pvc pipes.


    Features of UT661 Series Pipeline Blockage Detectors

    Certificates: CE, RoHS

    ● The location of the blockage in the pipe can be detected
    ● Measurable pipe material: plastic pipes, metal pipes

    ● Maximum detection distance(depth): 50cm
    ● Buzzing prompt and Flash prompt


    Specifications of UT661 Series Pipeline Blockage Detectors

    SpecificationsUT661D
    TransmitterYes
    Signal wire35m
    ReceiverYes
    Maximum detection distance(depth)50cm
    Transmitter currentShutdown current: <2uA, working current: 230~310mA
    Receiver currentShutdown current: <2uA, standby current: <40mA
    Maximum working current: 150~450mA (Distance 1cm)
    Charging current450~550mA
    Test the output sound at a distance of 1cm>93dB
    Test the output sound at a distance of 0.5m>75dB
    Battery duration10 hours
    Operting temperature and humidity-20°C~60°C, 10~80%RH
    Measurable pipe materialPlastic pipes, metal pipes
    Buzzing promptYes
    Flash promptYes
    Low battery indicationYes
    Waterproof gradeProbe waterproof IP67
    General Characteristics
    Transmitter batteryBuilt-in lithium battery (3.7V 1800mAh)
    Receiver batteryBuilt-in lithium battery (3.7V 1800mAh)
    ColorRed and grey
    WeightTransmitter: 1.24KG
    Receiver: 0.26KG

    External dimensionTansmitter: 38x30x42mm
    Receiver: 40x38x80mm
    Standard accessoriesCharging cable, Probe kit
    Standard individual packingGift box, English manual, Warranty card
    Standard quantity per carton5pcs
    Standard packing size405x90x350mm
